60mm Tangential Blower Cross Flow Fans 230V 50HZ For Freezers

Name: 60mm Tangential Blower Cross Flow Fans 230V 50HZ For Freezers
Brand: Zhaoli
Price: 1 USD

Wholesale 60mm Tangential Blower Cross Flow Fans 230V 50HZ For Freezers from china suppliers

Brand Name : Zhaoli

Model Number : 60-300

Certification : UL, CUL, CE, VDE, CCC, ROHS, REACH

Place of Origin : China

MOQ : 1000pcs

Payment Terms : L/C, T/T, Western Union

Supply Ability : 300,000pcs per day

Delivery Time : 20-40 days

Packaging Details : cartons + wooden pallet

Name : Tangential Blower Fan

Rated voltage : 220-240V 50/60HZ

Motor model : YJ61-25

Insulation class : CL.H

Motor protection : Impedance protected

Blower size : 60x300mm

Blade material : aluminium alloy

Frame : Galvanized sheet steel

Bearing : ball bearing or sleeve bearing optional

Mounting : 4 directions flexible

Color : mainly original silver or black

Printing : Customized printing

Packing : Customized packing

Application : Air curtain/Air conditioning/Freezers/Fireplaces

Contact Now

Tangential Blower Fan Cross Flow Fan 60/65mm Blower Size 300mm Long 220-240V 50HZ

Specification:

Motor Type	AC shaded pole motor YJ61-25
Blower size	60X300mm
Rated voltage/frequency	230V 50HZ
Starting voltage	<= 176V
Rated current	<= 0.5A
Rated power	40+/20% W
Rated speed	2100+/- 10% RPM
Rising Temp.	IEC60335-1
Lock Temp.	IEC60335-1
High-voltage test	1800VAC/2mA/1S
Cold insulation resistance	>= 100MΩ
End play	1.0mm max

Drawing:

60mm Tangential Blower Cross Flow Fans 230V 50HZ For Freezers

Application: This kind of cross flow fan is widely used in different industries, like hotels, construction works, home use appliances and so on. For example, Air curtain, Air conditioning, Freezers, Electric Fireplaces, Oven, Heater fan.

60mm Tangential Blower Cross Flow Fans 230V 50HZ For Freezers
